Step Up and Down Voltage Transformer Converters

Brand:

Transmart

Model：:

Desktop Series, Vertical Series

MOQ:

100 PCS per item

Origin:

China Foshan

Lead time:

4-15 Working days

Payment:

L/C D/A D/P T/T Western Union

Service:

OEM, ODM, Customized

Inquiry

Write a Review

DESKTOP SERIES

Step up / down voltage transformer Converters

Part No.	Input/Output (v)	Dimension LxWxH (mm)	Weight (kg)	Rated Power （VA）	Max. Power （W）	PTC thermal pro. (105℃)	Surge-Pro	Voltage display	Outlet（pcs）
VC-250	220/110+100 110/220x2	215x153x52	1.8	/	250	●	●	○	2
VC-500		215x153x52	2.7	/	500	●	●	○	2
VC-750		215x153x52	3.5	/	750	●	●	○	2
LX-300		215x153x52	3	450	450	●	●	●	2
LX-500		215x153x52	4	750	750	●	●	●	2

VERTICAL SERIES

Step up / down voltage transformer Converters

Part No.	Input/Output (v)	Dimension LxWxH (mm)	Weight（kg）	Rated Power（VA）	Max. Power（W）
VC-1000	220/110x2 220/100x2 110/220x2	220x175x60	4.5	/	1000
VC-1500		220x175x60	5.3	/	1500
VC-2000		240x185x70	6.3	/	2000
VC-2500		240x185x70	7.2	/	2500
VC-3000		240x185x70	8	/	3000
LX-800	220/110+100 110/220x2	220x175x60	4.5	800	1040
LX-1200		220x175x60	6	1200	1560
LX-1600		240x185x70	7.5	1600	2080
LX-2000		240x185x70	8.5	2000	2600
LX-2400		240x185x70	9.5	2400	3120

Step Up and Down Voltage Transformer Converters 7

Step Up and Down Voltage Transformer Converters 8

Step Up and Down Voltage Transformer Converters 9

STEP UP / DOWN VOLTAGE TRANSFORMER CONVERTERS

A voltage transformer is used to convert the electrical output of a power source to match the voltage of your device, that is, to convert 110 volt to 220/240 Volt OR convert 220/240 V to 110/120 Volt. A Step Up transformer is needed when you want to use a 220 volt foreign appliance in USA with 110v. A Step Down transformer is needed when you want to use a 110V appliance in a 220V Country.

We produce a wide range of 110 Volt and 220 Volt Step up and step down voltage converter transformers. Our Step Up Down transformers are reversible and can be used worldwide with 110v-240v and 50Hz or 60 Hz. Also called power converters, most of our transformers come with Universal outlets that can accept plugs from most foreign countries.

FEATURES

1.Slim and modern design

2.Toroidal transformer inside / Low losses

3.International Compatibility: Two outlets for 220V rated appliances from EURO, China, Korea, HK, Philippine, etc.
4.Safety: CE & CQC Certified! Comes with LED indicator, overloading alarm and built in short circuit and surge protection;
5.Surge-protector: all our 110v to 220v step up voltage converter is equipped with surge-protector to protect your home circuit from circuit breakers trip and fuse block
